Gerillte Nieten Aluminium/Stahl (Ø x L) 4,8 x 18,0 mm mit Flachkopf – Gerillte Blindnieten – Niete – RILLI
€36.11
| Artikel | Gerillte Blindniete RILLI AL/ST – Flachkopf – 4,8x18 mm |
| Artikelnummer | 7070248180 |
| Produkttyp | Gerillte Blindniete |
| Markenname | RILLI |
| Hersteller | Goebel GmbH |
| Werkstoff Dorn | Stahl |
| Oberfläche Dorn | Stahl verzinkt |
| Werkstoff Hülse | Aluminium AlMG 2,5 |
| µ–Wert | 3–5 |
| Kopfform | Flachkopf |
| Durchmesser (mm) | 4,8 |
| Durchmesser Kopf (D2) | 9,5 + / – 0,29 mm |
| Nietdorn Durchmesser (d) | 2.65 mm |
| D1 Toleranz | 4,8 + 0,35 / – 0 mm |
| Nenndurchmesser (D1) | 4.8 mm |
| Bohrer (Durchmesser–Vorbohren) | 5,1 mm |
| Länge (mm) | 18,0 |
| Länge (L) Toleranz | + 1,0 / – 0,2 mm |
| Länge Nietdorn (P) | ≥ 27,0 mm |
| Kopfhöhe (k) | ≤ 2,0 mm |
| F–Max | 22.5 mm |
| Scherbruchlast | 1185 N |
| Zugbruchlast | 1575 N |
| Klemmbereich max. | 14,0 mm |
| Geeignet für | Innen |
| Passendes Werkzeug | GO–3, GO–55, GO–360, EL–48–R, GO–40, EL–64–R, GO–25–SN, EL–64–N, GO–12–R, AIRPOWER 1, AIRPOWER 2, AIRPOWER 3, GO–BR1, GO–TR1, GO–BR2 |
| VPE | 500 |
